Input Voltage And Current
When the meter is in power measurement mode, if input voltage
exceeds 600V(TRMS)or current exceeds 1000A (TRMS), the meter
will display “OL” symbol, and bar graph is full. When input voltage
exceeds 30V, the “ ” symbol is shown in the display for safety.
Backlight Display
When press button, backlight of LCD display is on. After
lighting for 4 seconds the backlight is self-off.
Sketch Of Safety Holding
Use the wrist-webbing to prevent a accidentally drop as shown in
Figure 19.
( Figure 19 )
- 26 -
IEC1010-1 IEC1010-2-032
600V II POLLUTION DEGREE 2
WARNING
ENOP
CAT.I
PLEASE READ MANUAL FOR SAFETY.TO AVOI D
ELECT RICA L SHOCK NEVER CONNECT THE TES T
LEADS TO THE INPUT JACKS WHICH ARE NOT
FORRELATED M EASURI NG AND REMOVE ALL
INPUTS BEFORE OPENI NG CASE.
BATTERIES : X 1.5 V SIZE AA 4
