Range Resolution Accuracy
200μF 0.1μF ±(2.2% +30)
2000μF 1μF ±(2.2% +30)
20mF 10μF ±(2.2% +30)
200mF 100μF Unspecified
Notes:
Above accuracies for film capacitor or better can be guaranteed within the full range.
Above specification from 20nF to 2uF ranges are specified under REL mode. The reading is calibrated to zero by
relative function when input is floating.
Logic Frequency:
Frequency Range Signal Accuracy
20Hz
～
220MHz Vpp 3V square wave ±(0.06% +10)
Linear Frequency:
Input Range AC Sensitivity (TRMS sine wave)
5Hz~10KHz 10KHz~100KHz
200mV 5mV 10mV
2V 50mV 100mV
20V 500mV 1000mV
200V 5V 10V
