Mastech MS8040 - Chapter 6 Accessories; Replacing the Battery

BENCH MODEL MULTIMETER
Input Range AC Sensitivity (TRMS sine wave)
5Hz~10KHz 10KHz~100KHz
750V 50V(Note 1) Unspecified
200μA 5μA(Note 1) Unspecified
2000μA 50μA(Note1) Unspecified
20mA 50μA(Note 1) Unspecified
200mA 5mA(Note 1) Unspecified
10A 500mA(Note1) Unspecified
Note 1
：
Freqency response 50Hz~10KHz.
Duty
Duty Scale
Accuracy
5%
～
95% ±10%
ClAMP
Range Resolution Accuracy
DC 220A 0.01A ±
（
0.1%+10
）
DC 2200A 0.1A ±(0.1%+10)
AC 220A (50
～
60Hz) 0.01A ±(1%+30)
AC 2200A(50
～
60Hz) 0.1A ±(1%+30)
Temperature
Range Resolution Accuracy
33
