MPPT Solar ChargeMaster 25 – User and Installation Manual
11
Figure 7: Load connected directly to the battery
Above schematics are to illustrate the general placement of the Solar ChargeMaster in a circuit. They are not meant to provide
detailed wiring instructions for any particular electrical installation.
Battery temperature sensor
BATTERY
Load
Battery fuse
Load fuse
PV-array
External DC-switch
(see section 3.4)
