38 CONTENTS
Ambient tempera-
ture
0 up to 45 C 0 up to 60 C 0 up to 45 C
Storage tempera-
ture
-20 up to 70 C
Humidity 10 up to 90 % non-condensing
Dimensions
Length 147 mm 155 mm
Width 95 mm 111.5 mm
8.1.4 Device Feature And Property Lists
8.1.4.1 mvHYPERION-CLm
8.2 mvHYPERION-32R16
8.2.1 Block diagram
The following block diagram shows schematically how the mvHYPERION-32R16 is designed.
Figure 13: mvHYPERION-32R16 block diagram
