Figure 16: mvHYPERION-HD-SDI-2 block diagram
8.3.2 Connectors
Figure 17: mvHYPERION-HD-SDI-2
8.3.2.1 Use of J1..J2
Connector usage mvHYPERION
-HD-SDI-2
J1 Camera 1 (3G/HD-SDI signal)
J2 Camera 2 (3G/HD-SDI signal)
