8.3 mvHYPERION-HD-SDI 41
Audio
2 (Cinch)
Resolution
Digitalization According to D1 digital video format
Storage According to D1 digital video format
Memory format YUV 4:2:2 packed/planar
Interface
Bus PCI Express® x4
Continuous data rate Max. 640 MB/s
Peak data rate Max. 1 GB/s
Payload size Up to 256 Bytes
Current consumption
PCIe 3.3V 5W
PCIe 12V 4W
Environmental conditions
Ambient temperature 0 up to 45 C
Storage temperature -20 up to 70 C
Humidity 10 up to 90 % non-condensing
Dimensions
Length 170 mm
Width 111.1 mm
8.3 mvHYPERION-HD-SDI
8.3.1 Block diagram
The following block diagram shows schematically how the mvHYPERION-HD-SDI is designed.
