8.3 mvHYPERION-HD-SDI 47
Interface
Bus PCI Express® x4
Continuous data rate Max. 640 MB/s
Peak data rate Max. 1 GB/s
Payload size Up to 256 Bytes
Current consumption
PCIe 3.3V Max. 1A
PCIe 12V Max. 0.05A + camera power
Camera supply Via PCI Express® 12V fused
Environmental conditions
Ambient temperature 0 up to 45 C
Storage temperature -20 up to 70 C
Humidity 10 up to 90 % non-condensing
Dimensions
Length 155 mm
Width 111.1 mm
MATRIX VISION GmbH
