Matrix ETERNITY ME

Matrix ETERNITY Quick Start 89
ETERNITY ME SLT8
L1
1
2
RJ45-1
(Blue)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 01
SLT 02
SLT
SLT
04
Connector
Color
Connection H/w Port Offset
RJ45-2
(Orange)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 05
SLT
06
SLT
SLT
08
