Matrox 4Sight EV6 - Environmental Specifications; Electrical Specifications

Environmental specifications 71
Environmental specifications
• Minimum/maximum ambient operating temperature: 0 to 50°C (32°F to 122°F).
• Minimum maximum storage temperature: -40 to 85°C (-40°F to 185°F).
• Operating relative humidity: 10 to 90% relative humidity (non-condensing).
• Storage humidity: 5 to 95% relative humidity (non-condensing).
• Pollution degree 2 environment.
• Designed for indoor use only.
Matrox 4Sight EV6 electrical specifications
Electrical specifications
•9 V
dc
to 27 V
dc
(0% tolerance)
1
Matrox 4Sight EV6
Steady-state current 15 A @ 9 V to 5 A @ 27 V (135 W)
Processor consumption 25 W (Thermal design power)
Energized power connection
85 A (peak) @ 24 V
1
1. The inrush current during initial energized power cable connection, caused by the input filter capacitor, is 85 A (peak) and
lasts for approximately 200 μsec. When the power cable is already connected and the power supply is turned on, the inrush
current is insignificant and might produce a surge current of 0 to 5 A above the average current consumption, depending on
the slope of the power supply voltage rise.
Typical inr ush cur rent
2
2. These measurements were taken using one unit, under testing conditions.
V
dc
In
Transition from G3 to G2/S5
3
3. This state is also known as going from mechanical-off to soft-off.
Transition from G2/S5 to S0
4
4. This state is also known as going from soft-off to full-on.
9 V 2 A 3 A
12 V 1.8 A 2 A
24 V 0.8 A 1 A
Enabled PoE consumption +48 V
dc
(15.4 W) / port
1. The input voltage range applies at the power connector of the unit. Ensure that the
selected power supply, wire gauge, and length of cable meet these requirements.
