Matrox 4Sight EV6 - Internal Connector Pinouts

Pinout descriptions of internal connectors 81
Pinout descriptions of internal connectors
Inside the unit on the motherboard, there are the following connectors:
• One M.2, socket 3, connector.
• Two SATA data connectors.
• One SATA power connector.
• Recovery connector.
• A RS-485 termination connector.
SATA data
connectors
Recovery
connector
M.2
connector
RS-485
termination
connector
Matrox 4Sight motherboardEV6
Internal connectors
SATA power
connector
Back panel
Front panel
