Matrox 4Sight EV6 - Front Panel Connectors

Pinout descriptions of external connectors 73
Pinout descriptions of external connectors
Matrox 4Sight EV6 features connectors on the front panel and back panel.
Front panel connectors
The following connectors are on the front panel of your unit:
• 4 USB 3.0 connectors.
• 2 USB 2.0 connectors.
• 4 Gigabit Ethernet connectors with PoE support.
• 2 Gigabit Ethernet connectors without PoE support.
• 1 DVI-I connector.
• 1 DisplayPort connector.
Back panel
Front panel
USB 3.0
LAN
2
LAN
1
USB 2.0USB 3.0
1
2
3
4
1
2
Yellow - Act/Link
Green - 100 Mbps
Orange - 1 Gbps
DP
DVI-I
3
4
1
2
PoE
HDD
On
Input Rating
9-27 VDC
1- A55
COM1
-232 / 485RS
RS-232
COM2
Audio
OUT
IN
Output
Input
LEDs
Power
button
