• 2 video output ports (DisplayPort and DVI-I) that allow you to connect either
two digital display devices or one digital and one analog display device; they can
be enabled simultaneously for a dual-monitor display (extended desktop or cloned
desktop). Only the DVI-I port supports analog output. The DVI-I port also
supports the HDMI 1.4 standard.
• 1 audio controller with support for line-level stereo audio input and output (for
example, from a microphone with a pre-amplifier or a speaker with an amplifier).
• Power management features.
Mass storage
• A 64-Gbyte
1
M.2 solid state drive (SSD) comes pre-installed from the factory in
the Matrox 4Sight EV6 unit. This SSD is connected to an M.2 2280 M key
connector (which supports PCIe 3.0 x 2 NVMe M.2 SSDs and SATA 3.0 M.2
SSDs).
• 2 SATA data connectors, which can be used to attach up to 2 more mass storage
devices.
Important Matrox 4Sight EV6 only supplies 5 V to the SATA power connector. Therefore,
storage devices requiring a 12 V supply are not supported.
Display Device Connector
Maximum display resolution
1
1. For more information, refer to the specification of the Intel Core i5-7442EQ processor.
Digital display device DisplayPort 4096 x 2304 @ 60Hz, 24bpp
Digital display device DVI-I (using single link DVI
standard)
2560 x 1600 @ 30 Hz, 24bpp
or
1920x 1200 @ 60 Hz, 24bpp
Digital display device
DVI-I (using HDMI standard
2
)
2. To access HDMI resolution, you must use a DVI-to-HDMI adapter. This adapter is not included with your unit.
4096 x 2160 @ 30 Hz, 24bpp
Analog display device
DVI-I
3
3. To connect an analog device, you must use the DVI-to-HD15 adapter included with your unit.
2048 x 1536 @ 50 Hz, 24bpp
or
2048 x 1152 @ 60 Hz, 24bpp
1. The size of the SSD is subject to change without notice, but will at minimum be
64 Gbytes.
