4)
Menu Guidance
Panel
The picture below
shows the control panel
Switch On
The follow
ing picture appears after boot routine
.
(Note: The picture
above may
not the original picture for y
our
controller)
There is no need
to connect your D1 Device to th
e first port.
Each device can be conne
cted to any free port of NCD
.
Stop-Key
Start-Key
Enable-Key
Reference-Key
Menu-Key
Device selection
Switch Device 1-5 t
o 5-8
Keyboard
USB-Ports
Power switch
F-Keys
7
6
8
