2) Technical Data of Controller NCD
The Multiple Control Device NCD is suited for the operation of up to 8 devices with multiple
axis of motion. Those devices can be any combinations of antenna masts, turntables, cable
guide rails or any other positioning equipment.
This controller NCD permits the operation in manual, semi-automatic and remote control
mode via IEEE 488.2 (GPIB bus), or optionally other interfaces, of multiple devices
simultaneously.
Figure: NCD with option “tip-up handle”
Technical Data
Data interfaces IEEE 488.2 (GPIB-Bus) and Ethernet
Transmission Fibre optic cable 1G50/125 (up to 2000 m distance)
Transfer rate 100 Mbit/s (fast Ethernet)
Display 5.7“ TFT Touch screen-Display
Voltage 100-240 VAC, 47-63 Hz, single phase
Current consumption max. 70W
Fuse 2x T 1.6A
Size (W X D) 19” Rack mount and table unit (427 x 300 mm)
Height 3 HE (133 mm)
Temperature range 5°C - 40°C
Total weight approx. 8 kg
Accessories 1.5 m power supply cable, Service manual
4
