OPERATOR INTERFACE OI-TS 4 - 2
D-MAXE with OI-TSwww.maxcessintl.com MI 2-292 1 C
OI-TS bedienen.fm
Buttons and Displays
The entry in a menu is accepted
The entry in a menu is rejected
Return to the previous menu level
Switch between the pages of a menu
Buttons represented in colors can be operated in the current
operation state.
Buttons represented completely in gray cannot be operated in
the current operation state.
Fields filled in with white show information and cannot be
operated.
To enter numbers, set the desired value with the + and -
buttons.
Sequences are a defined succession of menus to be processed
by the user step by step.
The next step can be reached by pressing the button in the
middle of the display.
