TECHNICAL DATA 11 - 1
D-MAXE with OI-TSwww.maxcessintl.com MI 2-292 1 C
TechnDaten.fm
11 TECHNICAL DATA
General information
D-MAXE Controller Power supply
24 to 48V nominal
21V minimum to 51V maximum
The negative pole serves as a signal ground and is electrically
connected with the housing.
[NOTE 1]
Maximum power consumption
D-MAXE Controller - connection for control
130W maximum
D-MAXE Controller - connection for drive
200W maximum at 24V or
400W maximum at 48V
Dimensions
Length: 184mm [7.24 in] without cables
Width: 87mm [3.45 in]
Height: 60mm [2.36 in] D-MAXE 1, D-MAXE 2
93mm [3.66 in] D-MAXE 3
Weight
1.0kg [2.2 lbs] D-MAXE 1, D-MAXE2
1.2 kg [2.65 lbs] D-MAXE 3
Protection class
IP54 according to DIN EN 60529
Ambient conditions
Ambient temperature: 0°C to 60°C [32 to140°F]
[NOTE 2]
Relative humidity: 10% to 95% non-condensing
Altitude above sea level: maximum 3000m [9842 ft]
Maximum output current
4.0A/drive
Fuse protection
Control power - 6.3A delay
[Bussmann S506-6.3-R or Littelfuse 021806.3P]
Drive power - 10A delay
[Bussmann S506-10-R or Littelfuse 0218010.P]
NOTE 2. The unit should always be mounted with good thermal
contact to a large metal body such as a guide or machine frame.
Some applications with very large drive and accessory load
currents may require ambient temperature de-rating.
