EN
Display Connections
Connecting a PC
Using PC Video Input
Connect the red (R) and white (L) audio jacks
from the PC to the R and L inputs located next
to the PC-IN Connector.
For most PCs, connect the 15-pin D-Sub RGB
connector from the back of the PC to the PC-IN
Connector located on the back of the PC.
Audio
(3.5 mm Mini-Stereo to RCA cable)
RGB Cable
(15 Pin D-Sub)
Setting Up Your TV Using Plug and Play
This TV adheres to VESA Plug and Play standard to eliminate complications when setting up the TV. This TV
identifies itself to the computer and automatically sends the PC its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols.
How to Set up Your PC for Use with TV (Windows)
The display settings for a typical Windows-based computer are shown below; however, actual screens on your
computer will differ depending on the version of Windows and video card equipped with the computer. Even
though the actual screen may look different from example displayed below, basic set-up routine will apply in
most cases.
Go to Window’s CONTROL PANEL by clicking:
START, SETTINGS, CONTROL PANEL. The
CONTROL PANEL Window is displayed.
Select the DISPLAY icon from this window.
To Next Page
