Appendix
75
EN
Specifications for 42” TV
Display Panel
Screen size 42”
Aspect ratio 16:9
Number of pixels 1024 (Horizontal) x 768 (Vertical)pixels
Pixel Pitch 0.192 (Horizontal)mm x 0.693 (Vertical)mm
Luminance 1000 cd/m
2
, at APL13%
Power Source
Input voltage 100 ~ 240Vac, 50 / 60Hz
Input current 3.5A Max. (at 110Vac)
Inrush current 67A p-p/20ms Max. (at 240Vac)
Power consumption 380 Watts (at 110Vac/color bar pattern)
Stand-by 1 Watts Max. (at 110Vac)
Connection
Connector Types Video Composite jack X 2 sets
S-Video jack (4 pin Din S-Terminal) X 1 set
Video Component RCA jack X 1 set
PC (15 pin D-SUB) X 1 set
HDMI (19 pin) X 2 set
USB X 1 set (for service only)
Audio L/R jack X 5 sets
RF input X 1 set
RS-232 (9 pin D-SUB) X 1 set
Video/S-Video Signal
Type Analog
Polarity Positive
Amplitude d. Video 1Vp-p, (priority S-Video) Y=1Vp-p C=0.286Vp-p
Frequency H: 15.734KHz V: 60Hz (NTSC)
H: 15.625KHz V: 60Hz (PAL)
Input impedance 75 ohms
Y/CB/CR or Y/PB/PR Signal (Component 1 & 2)
Type Analog
Polarity Positive
Amplitude AV: 1Vp-p (with sync)/750 ohms
S-Video: Y: 1Vp-p, C: 0.286Vp-p
Frequency
Y/CB/CR H: 15.734KHz V: 60Hz (NTSC)
Y/PB/PR: HDTV H: 31KHz V: 60Hz (480p)
H: 45KHz V: 60Hz (720p)
H: 33KHz V: 60Hz (1080i)
PC Signal
Type TTL
Polarity Positive or Negative
Amplitude PC: 0.7Vp-p
Frequency H: support to 31K ~ 64KHz
V: support to 50 ~ 7KHz
