Picture Controls
32
EN
Selecting Signal Source for Sub-Picture
Various signal sources can be displayed within the sub-window under PIP picture mode. To select the input
source for sub-window, please follow the steps below.
Once the PIP mode is turned on, you can
change the sub-picture input source by press-
ing the key.
Source
Select
Pressing the key repeatedly will cycle
through all available inputs for the sub-picture.
Note:
Please see reference table on next page for available PIP input combinations.
Sub-Picture feature is not available under S-Video input mode.
Picture-in-Picture
Turning On PIP
PIP feature allows users to view two video input sources simultaneously.
Press the key once on the remote control
to engage in Picture-in-Picture mode. Pressing
the key repeatedly will cycle thru the following
modes:
PIP Key
Sub Picture
Input Source for
Main Picture
Input Source for
Sub Picture
PIP Mode
MAIN:TV
PIP: AV1
Main Picture
When engaged in PIP mode, a small window is
displayed in one of the four corners. The OSD
on the upper right corner will denote the input
selected for main picture (large screen) and the
sub-picture (small screen) displayed.
Note:
Once PIP is turned off, the next time you
return on PIP mode, the position of the sub-
window will start at default position.
PIP feature is only available under TV input
mode.
