OPERATING INSTRUCTIONS
4-11
Fill Segment (Fill 1 through Fill 5)
Display
Details
Use Up or Down to change. Start key is enter or advance
FIL 1 FIL 2 FIL 3 FIL 4 FIL 5
dr In or Srin
(1) Select Rinse Method: Dilution Rinse or Spray Rinse
00 or 02 - 30
(2) Segment time: 00 to skip, or any time between 0 and 30 min
HFIL cFIL bFIL
(3) Fill temperature: Hot, Cold, or Warm (both fill)
LoLE or hILE
(4) Select Fill level, Low or High
SUP0 – SUP7
(5) Select Supply 0-7 (0 for no supply during the step)
00, 75 - 200
(6) Enter temperature: 75-200 deg F, 25-93 deg C, 00 for no heat. Select 00 if
you have programmed a Flushing Prewash
00, 25 - 93
SPIn flases for 1 sec
t IrE flases for 1 sec
00 or 30 - 120
(7) Select time for spin: 30 – 120 seconds. 00 for no spin
NOTE: Supply 4 and 7 are only available if enabled in Setup
NOTE: Heat is only available if enabled in Setup
NOTE: If Spray Rinse is selected for the segment, steps 3 to 6 are skipped.
Fill 6 Segment
Display
detiail
Use Up or Down to change. Start key is enter or advance
FIL 6
00 or 02 - 30
Segment time: 00 to skip, or any time between 0 and 30 minutes
HFIL cFIL bFIL
Fill temperature: Hot, Cold, or Warm (both fill)
LoLE or hILE
Select Fill level, Low or High
SUP0 – SUO7
Select Supply 0-7 (0 for no supply during the step)
00, 75 - 200
Enter temperature: 75-200 deg F, 25-93 deg C. 00 for no heat Select 00 if you
have programmed a Flushing Prewash
00, 25 – 93
SPIn flases for 1 sec
t IrE flases for 1 sec
00 or 30 - 120
Select time for spin: 30-120 seconds. 00 for no spin
NOTE: Supply 4 and 7 are only available if enabled in Setup
NOTE: Heat is only available if enabled in Setup
