PROGRAM SPEEDS IN RPM FROM G-FORCE POINTS
EXTRAC RPM TO G-FORCE
Machine Cylinder Dia. 50 G 75 G 100 G 125 G 150 G 175 G 200 G 225 G 250 G
HE-20-30 0.612 m 382.4 468.4 540.8 604.7 662.4 715.5 764.9 811.2 855.1
SP/HP/HE-40 0.680 m 362.8 444.3 513.1 573.6 628.4 678.7 725.6 769.6 811.2
SP/HP/HE-60 0.790 m 336.6 412.2 476.0 532.2 583.0 629.7 673.2 714.0 752.7
HE-80 0.924 m 311.2 381.2 440.2 492.1 539.1 582.3 622.5 660.2 695.9
SP/HP-100 0.940 m 308.6 377.9 436.4 487.9 534.5 577.3 617.1 654.6 690.0
SI-110 0.940 m 308.6 377.9 436.4 487.9 534.5 577.3 617.1 654.6 690.0
SI-135 1.092 m 286.3 350.6 404.9 452.7 495.9 535.6 572.6 607.3 640.2
SI-200 1.169 m 276.7 338.9 391.3 437.5 479.3 517.7 553.4 587.0 618.7
SI-275 1.321 m 260.3 318.8 368.1 411.6 450.9 487.0 520.6 552.2 582.0
SI-300 1.321 m 260.3 318.8 368.1 411.6 450.9 487.0 520.6 552.2 582.0
SI-450 1.629 m 234.4 287.1 331.5 370.6 406.0 438.5 468.8 497.2 524.1
Machine Cylinder Dia. 275 G 300 G 325 G 350 G
HE-20-30 0.612 m 896.9 936.7 975.0 1011.8
SP/HP/HE-40 0.680 m 850.8 888.7 925.0 959.9
SP/HP/HE-60 0.790 m 789.4 824.5 858.2 890.6
HE-80 0.924 m 729.9 762.4 793.5 823.4
SP/HP-100 0.940 m 723.7 755.8 786.7 816.4
SI-110
0.940 m
723.7
755.8
786.7
816.4
SI-135 1.092 m 671.4 701.3 729.9 757.5
SI-200 1.169 m 648.9 677.8 705.5 732.1
SI-275
1.321 m
610.5
637.6
663.6
688.7
SI-300 1.321 m 610.5 637.6 663.6 688.7
SI-450 1.629 m 549.7 574.2 597.6 620.2
Machine Cylinder Dia. 0.4 G 0.8 G 1.0 G 1.5 G 3.0 G 50 G 150 G 320 G 350 G
HE-20-30 0.612 m 34.2 48.4 54.1 66.2 93.7 382.4 662.4 967.5 1011.8
SP/HP/HE-40 0.680 m 32.4 45.9 51.3 62.8 88.9 362.8 628.4 917.5 959.9
SP/HP/HE-60 0.790 m 30.1 42.6 47.6 58.3 82.4 336.6 583.0 851.5 890.6
HE-80 0.924 m 27.8 39.4 44.0 53.9 76.2 311.2 539.1 797.4 823.4
SP/HP-100 0.940 m 27.6 39.0 43.6 53.4 75.6 308.6 534.5 780.6 816.4
SI-110 0.940 m 27.6 39.0 43.6 53.4 75.6 308.6 534.5 780.6 816.4
SI-135 1.092 m 25.6 36.2 40.5 49.6 70.1 286.3 495.9 724.3 757.5
SI-200 1.169 m 24.7 35.0 39.1 47.9 67.8 276.7 479.3 700.0 732.1
SI-275 1.321 m 23.3 32.9 36.8 45.1 63.8 260.3 450.9 658.5 688.7
SI-300 1.321 m 23.3 32.9 36.8 45.1 63.8 260.3 450.9 658.5 688.7
SI-450 1.629 m 21.0 29.6 33.1 40.6 57.4 234.4 406.0 593.0 620.2
