Maxi MWHE20 - Page 80

20 lb. 30 lb. 40 lb. 60 lb. 80 lb.
1
----A0-A005-149 2 Seal, O-Ring
----A0-A005-103 1 Seal, V-ring (STD)
----A0-A005-042 1 Seal, V-Ring (Option)
3
----A0-A006-022 1 Collar Seal
----A0-A005-015 2 Seal, Oil (STD)
----A0-A005-043 2 Oil Seal (Option)
5
----A0-A004-011 1 Bearing
6
----A0-M011-049 1 Basket Shaft
7
----A0-A004-001 1 Bearing
8
----A0-A006-017 1 Lock, Washer
9
----A0-A006-016 1 Lock, Nut
10
----A0-A005-101 1 Seal, V-Ring
11
----A1-SSP2-019 1 Seal Plate, Front
12
----A1-SSP2-021 1 Seal Plate, Flat Front
13
----A0-P006-070 3 fitting
14
----A0-A106-004 1 Hose Nipple
15
----A0-A007-012 1 Housing
16
----A1-SSP2-020 1 Seal Plate, Rear
17
----A1-S802-047 1 Set Bearing Housing Complete set
Part No.
Description
Section 8
Qty.
Part List : Bearing Housing Assembl
y
Page 15
Item
2
4
4
3
2
1
6
5
7
9
11
13
15
8
10 12
14
16
17
