Maxi MWHE20 - Page 79

20 lb. 30 lb. 40 lb. 60 lb. 80 lb.
A1-SHE1-024 A1-SHE1-024 - - - 1 Seal plate, Flat
- - A1-SHE1-025 A1-SHE1-025 - 1 Seal plate, Flat
A0-A005-025 A0-A005-025 - - - 2 Seal
- - A0-A005-027 A0-A005-027 - 2 Oil Seal (STD)
- - A0-A005-129 - - 2 Oil Seal (Option)
A0-A004-110 A0-A004-110 - - - 1 Ball bearing, Front
- - A0-A004-112 A0-A004-112 - 1 Ball bearing, Front
A0-A007-045 ----1Housing
- A0-A007-016 - - - 1 Housing
- - A0-A007-043 A0-A007-043 1 Housing
A0-A004-067 A0-A004-067 - - - 1 Ball bearing Rear
- - A0-A004-111 A0-A004-111 - 1 Ball bearing Rear
A0-A106-003 A0-A106-003 - - - 1 Hose nipple
- - A0-A106-004 A0-A106-004 - 1 Hose nipple
A1-S204-030 ----1 SetBearing Housing Complete set
- A1-SHE1-026 - - - 1 Set Bearing Housing Complete set
- - A1-SHE1-027 A1-SHE1-027 - 1 Set Bearing Housing Complete set
4
7
6
5
Qty.
Page 14
Part List : Bearing Housing Assembly
Item
Part No.
Description
Section 8
1
3
2
1
2
3
4
5
6
7
