Maxi MWHE20 - Page 78

20 lb. 30 lb. 40 lb. 60 lb. 80 lb.
- - A0-E001-922 - - 1 Inverter 3 HP. 200-240V. 1PH.
- - - A0-E001-222 - 1 Inverter 5HP. 200-240V. 3PH.
2
- - A0-E006-029 A0-E006-029 - 1 Transformer
3
- - A0-E007-319 A0-E007-319 - 1 Power Supply 24VDC.
- - A0-E010-029 A0-E010-029 - 1 Circuit breaker 6A
- - A0-E010-031 A0-E010-031 - 2 Circuit breaker 1A
5
- - A0-E021-039 A0-E021-039 - 1 Terminal, Block 10P
--
A0-E021-031/1 A0-E021-031/1
- 1 Terminal Block 3 Pole
--
A0-E021-031/2 A0-E021-031/2
- 1 Terminal Block 4 Pole
7
- - A0-E055-001 A0-E055-001 - 1 Connector, Ground Lug
- - A1-ST01-005 - - 1 Electric enclosure, Rear
- - - A1-ST01-006 - 1 Electric enclosure, Rear
1
Section 8 Page 13
4
6
8
Part List : Electrical Control Uni
t
Item
Part No.
Qty. Description
4
2
1
8
6
3
7
5
4
2
1
8
6
3
7
5
Model 40 lbs. Hot Water Heating (220/60/1) Model 60 lbs. Hot Water Heating (220/60/1)
