11921 Slauson Ave. Santa Fe Springs, CA. 90670 (800) 227-4116 FAX (888) 771-7713
PUMP & MOTOR SOLENOID OPERATION - POWER DOWN
HYDRAULIC SYSTEM DIAGRAMS
POWER UNIT MOTOR & SOLENOID OPERATION - POWER DOWN
LIFTGATE
FUNCTION
PORT
SOLENOID OPERATION ( MEANS ENERGIZED)
SWITCH RELAY MOTOR
VALVE
“B”
VALVE
“C”
VALVE
“D”
VALVE
“E”
VALVE
“H”
LIFT B
“PD”
------
LOWER C - - -
OPEN J - - - -
CLOSE A - - - - -
REFER TO VALVES SHOWN ON HYDRAULIC SCHEMATIC
TABLE 96-1
“M” SOLENOID
“E” VALVE
“B” VALVE
“H” VALVE
“D” VALVES
(TOP OF EACH COLUMN)
FIG. 96-3
“D” VALVE
FIG. 96-1
BUCHER PUMP “B” VALVE
FIG. 96-2
“C” VALVE
“B” VALVE
