3.6.3 NET Port
The LED (Figure 3-40; C) displays the link activity of the NET port (applies for both ports, X14 “IN” and
X15 “OUT”):
• Green LED indicates link activity
Table 3-80 NET Port LED
LED
Description
Green
OFF Port is closed
Flicker Port is open / activity is present
ON Port is open
— Data rate is 100 Mbit/s
Flicker = continuous flickering (10 Hz)
