Setup

Cabling

EPOS4 Disk 60/12 Hardware Reference

3-20 CCMC | 2022-05 | rel10685

3.2 Cabling

PLUG&PLAY

Take advantage of maxon’s prefab cable assemblies. They come as ready-to-use parts and will help to

reduce commissioning time to a minimum.

a) Check the following table and find the part number of the cable assembly that matches the

setup you will be using.

b) Follow the cross-reference to get the cable’s pin assignment.

Table 3-9 Prefab maxon cables

Connector

Prefab Cable Assembly

Designation

Part

Number

Page

X1a

Power Cable High Current 710929 3-49

X2a

Power Cable High Current

Power Cable

710929

275829

3-49

X3 Motor Cable High Current 710930 3-50

X4 Hall Sensor Cable 275878 3-50

X4a Hall Sensor Cable 696284 3-50

X5/X6 Sensor Cable 5x2core 520852 3-51

X5 Encoder Cable 696285 3-51

X6 Sensor Cable 3x2core 696286 3-51

X7a

Signal Cable 8core 696287 3-52

X8a

Signal Cable 7core 696288 3-52

X13

X13a

USB Type A-Micro-Lock Cable 696289 3-52

X14

X14a

CAN-CAN Cable

CAN-COM Cable

710931

710932

3-53

X14

X14a

EtherCAT-EtherCAT Cable

EtherCAT-COM Cable

710933

710934

3-54

X15

X15a
