Maxon IDX 70 - Page 27

Electrical Installation
Cabling
IDX 70 User Manual
mmag | 2022-04 | rel10520
4-27
Table 4-9 Prefab cables
I/O
X3 X3 X3
IO M12A12F0 PUR S
BK 0150
M12, female, 12 poles, A-coded, straight
Open end
1.5 662957
X3 X3 X3
IO M12A12F0 PUR S
BK 0300
M12, female, 12 poles, A-coded, straight
Open end
3 662954
X3 X3 X3
IO M12A12F9 PUR S
BK 0150
M12, female, 12 poles, A-coded, 90°
Open end
1.5 662952
X3 X3 X3
IO M12A12F9 PUR S
BK 0300
M12, female, 12 poles, A-coded, 90°
Open end
3 662948
Power
X4
[i]
X4
[i]
X4
[i]
PR M230F50 PUR S
OG 0300
M23, female, 6 poles, N-coded, straight
Open end
3 711319
USB
X5 X5 X5
USB Type A - micro B
Cable
USB Type “micro B”, male
USB Type “A”, male
1.5 403968
[i] The IDX can be ordered in two types—with straight or with angled power connector X4. The
angled type can be rotated up to 90°.
Make sure that the rotated power connector and the attached outgoing cable do not block out or
damage any other connector.
Connector Prefab cable assembly
IDX
CANopen
IDX
EtherCAT
IDX
I/O
Designation
Identifier key
Figure 2-7
Connector #1
Connector #2
Length
[m]
Part
number
