Electrical Installation

Cabling

IDX 70 User Manual

4-26 mmag | 2022-04 | rel10520

4.2 Cabling

To make installation easy, fast, and error-free, a wide selection of prefab cable assemblies is available.

They are made to meet all requirements in respect to electromagnetic compatibility and guarantee interfer-

ence-free operation of the IDX. You can find information on the available cables in Table 4-9 and on their

identifier key in Figure 2-7.

Wrong cabling can cause unexpected electromagnetic disturbances

Using other cables may possibly cause unexpected electromagnetic disturbances that can jeopardize EMC-

conform, error-free operation.

Connector Prefab cable assembly

IDX

CANopen

IDX

EtherCAT

IDX

I/O

Designation

Identifier key

Figure 2-7

Connector #1

Connector #2

Length

[m]

Part

number

CANopen

X1 — —

CO M08B05F0 PUR S

PK 0150

M8, female, 5 poles, B-coded

Open end

1.5 662951

X1 — —

CO M08B05F0 PUR S

PK 0300

M8, female, 5 poles, B-coded

Open end

3 662935

X1 — —

CO M12A05M0 PUR S

PK 0015 M08B05F0

M8, female, 5 poles, B-coded

M12, male, 5 poles, A-coded

0.15 662946

X2 — — CO M08B05M0

M8, male, 5 poles, B-coded, (built-in

termination)

Termination

— 662933

X2 — —

CO M08B05M0 PUR S

PK 0150

M8, male, 5 poles, B-coded

open end

1.5 662950

X2 — —

CO M08B05M0 PUR S

PK 0300

M8, male, 5 poles, B-coded

Open end

3 662934

X2 — —

CO M08B05M0 PUR S

PK 0300 M08B05F0

M8, male, 5 poles, B-coded

M8, female, 5 poles, B-coded

3 662959

X2 — —

CO M12A05F0 PUR S

PK 0015 M08B05M0

M8, male, 5 poles, B-coded

M12, female, 5 poles, A-coded

0.15 662947

EtherCAT

—

ET M08A04M0 PUR S

GN 0150

M8, male, 4 poles, A-coded

Open end

1.5 662961

—

ET M08A04M0 PUR S

GN 0300

M8, male, 4 poles, A-coded

Open end

3 662941

—

ET M08A04M0 PUR S

GN 0150 R45004M0

M8, male, 4 poles, A-coded

RJ45

1.5 662956

—

ET M08A04M0 PUR S

GN 0300 R45004M0

M8, male, 4 poles, A-coded

RJ45

3 662942

—

ET M08A04M0 PUR S

GN 0300 M08A04M0

M8, male, 4 poles, A-coded

3 662960

Continued on next page.
