41
Preset
Multi-Registers
UCRONSET Double Optional
Preset
Multi-Registers
UCROFFSET Double Optional
Preset
Multi-Registers
CMD 33 mandatory
Table 18. CC mode switch to CV mode:
Operation Register Value Description
Preset
Multi-Registers
IFIX Double Optional
Preset
Multi-Registers
UCCCV Double Optional
Preset
Multi-Registers
CMD 34 mandatory
Table 19. CR mode switch to CR mode:
Operation Register Value Description
Preset
Multi-Registers
RFIX Double Optional
Preset
Multi-Registers
UCRCV Double Optional
Preset
Multi-Registers
CMD 35 Must select
Table 20. Battery test mode:
Operation Register Value Description
Preset
Multi-Registers
IFIX Double Optional
Preset
Multi-Registers
UBATTEND Double Optional
Preset
Multi-Registers
CMD 38 mandatory
Table 21. Dynamic Test Mode：
Operation Register Value Description
Preset
Multi-Registers
IA Double Optional
Preset
Multi-Registers
IB Double Optional
Preset
Multi-Registers
TMAWD Double Optional
Preset
Multi-Registers
TMBWD Double Optional
