BIO Disassembl
y Instructio
ns
Page
6
of
11
5. Dismant
ling the Cable
Step 5.1
Remove 2 f
loats
from the m
otor
unit.
Step 5.2
Unscrew the 4
screws securi
ng
the cabl
e holder
Step 5.3
Unscrew the
cable f
rom the
motor uni
t.
Step 5
.4
Unpl
ug the cable.
