BIO Assembly
Instructions
Page
7
of
14
6
.
Positioning the
Floats
Step 5.4
Position
the
floati
ng cable on
the motor un
it
and
secure the
cable h
olders
with 4
50X12
screws.
Step 5.5
The cable
position
on the
motor uni
t.
Step 6.1
Place t
he two
floats
on the
motor uni
t.
6
8
