BIO Assembly
Instructions
Page
5
of
14
4. Assembl
ing the Side Panel
s
Step 4.1
Put the si
de
panels i
nto place
on both si
des of
the robot.
Step 4.2
Secure the si
de
panels i
n place
with 4
KA50X20
screws on both
sides of
the robot.
Note:
Make
sure the
clips are
in place.
4
6
