MECHANICAL
01–10–32
CYLINDER BLOCK (II) ASSEMBLY
E5U011002000E09
1. Assemble in the order indicated in the table.
.
SEALANT
SEALANT
R
R
R
R
R
R
B
9
8
7
5
4
3
2
10
6
11
12
SST
13
1
A
A
A
A
A
A
30—39
{3.1—3.9,
22.2—28.7}
46—54 {4.70—5.50,
34.0—39.8}+76—84
{7.75—8.56,
56.1—61.9}+108—116
{11.1—11.8, 79.7—85.5}
16.2—23.8 {1.66—2.42,
12.0—17.5}
30—35
{3.1—3.5,
22.2—25.8}
15—20
{1.6—2.0,
11—14}
20—30
{2.1—3.0,
14.8—22.1}
N·m {kgf·m, ft·lbf}
8.0—12 N·m
{81.6—122.3 kgf·cm,
70.9—106.2in·lbf}
+20
°—25°
8.0—11.5 N·m
{81.6—117.2 kgf·cm,
70.9—101.7 in·lbf}
:
SPIN-ON
TYPE
CARTRIDGE
TYPE
WITH OIL COOLER
MTX
R
R
R
IF EQUIPPED
R
OIL
OIL
SST
WITHOUT OIL COOLER
17—23
{1.8—2.3,
12.6—16.9}
17—23
{1.8—2.3,
12.6—16.9}
8
E5U110ZE7S08
1 Rear oil seal
(See 01–10–33 Rear Oil Seal Assembly Note)
2 Oil pump
3 Oil strainer
4 Water pump
5 Thermostat
6 Oil separator
7 Knock sensor
8 Oil filter adapter
9 Oil cooler
10 Oil filter
11 Oil filter cover (cartridge type)
12 Oil pan
(See 01–10–34 Oil pan Assembly Note)
13 Flywheel (MTX), Drive plate (ATX) (See 01–10–33
Drive Plate (ATX), Flywheel (MTX) Assembly Note)
