Mazda 6 - Construction

K10
ELECTRONIC CONTROL SYSTEM
CONSTRUCTION
A6E561501030T02
.
A6E5614T007
1 HOLD indicator light
2 Speedometer
3 Brake switch
4PCM
5 HOLD switch
6 Throttle position sensor
7DLC
8 Mass air flow sensor
9 Engine coolant temperature sensor
10 Vehicle speed sensor
11 Input /turbine speed sensor
12 Crankshaft position sensor
13
Control valve (With transaxle fluid temperature
sensor and solenoid valves)
14 Transaxle range swich
15 Oil pressure switch
