Mazda 6 - Liftgate Lock Actuator

S10
POWER DOOR LOCK SYSTEM
End Of Sie
LIFTGATE LOCK ACTUATOR
A6A771862310T01
Outline
• Models equipped with the keyless entry system do not have a liftgate key cylinder. If there are malfunctions in
the keyless entry system with the liftgate locked, the liftgate cannot be unlocked. Instead, the liftgate lock
actuator can be unlocked manually from a newly- adopted access hole on the liftgate lower trim.
.
Operation
• The liftgate latch is switched from the lock to unlock position when the link plate is moved in the direction of
arrow (2) after the link plate is pressed in the direction of arrow (1) .
.
End Of Sie
A6A7718TS01
1Press
2 Link plate
3 Access hole
4 Liftgate lower trim
A6A7718TS02
1 Lock
2Unlock
3 Link plate
4 Liftgate lock actuator
5 Liftgate latch
6 Outer handle
