Mazda 6 - Page 46

LUBRICATION SYSTEM
D5
D
L3
1 Camshaft
2 Cylinder head
3 Cylinder block
4 Oil jet valve
5 Crankshaft
6 Oil filter
7 Oil filter bypass valve
8 Oil pump
9 Oil strainer
10 Oil pan
11 Return oil
12 Chain tensioner
13 LF engine model
14 Oil cooler
15 To oil filter
16 From oil pump
17 Oil pressure switch
18 Orifice
19 Piston
20 Main bearing
21 Crankshaft bearing, Connecting rod bearing
22 Oil pressure relief valve
23 Elevational view
24 Side view
AME3300N004
