CONTROL SYSTEM
F31
F
End Of Sie
1 MAF/IAT sensor
2 TP sensor
3 MAP sensor
4CMP sensor
5 CKP sensor
6ECT sensor
7Knock sensor
8 HO2S (front, rear)
9 P/S pressure switch
10 Vehicle speedometer sensor
11 Clutch switch
12 Neutral switch
13 TR switch
14 Brake switch
15 A/C switch
16 Refrigerant pressure switch
17 Generator (terminal P: generation voltage)
18 Battery
19 VAD control solenoid valve
20 IAC valve
21 VIC solenoid valve
22 VTCS solenoid valve
23 OCV
24 Fuel injector
25 Fuel pump relay
26 Ignition coil
27 Purge valve
28 EGR valve
29 Oxygen sensor heater (front, rear)
30 A/C relay
31 Cooling fan relay
32 Generator (terminal D: field coil)
33 VAD control
34 IAC
35 VIC
36 VTCS
37 Variable valve timing control
38 Fuel injection control
39 Fuel pump control
40 Electronic spark advance (ESA) control
41 Purge control
42 EGR control
43 Oxygen sensor heater control
44 A/C cut-off control
45 Electrical fan control
46 Generator control
