Form No.3351-1A-01A
D-2
LUBRICATION MECHANISM
STRUCTURAL VIEW AND LUBRICATION FLOW DIAGRAM
1 Oil pan
2 Oil strainer
3 Oil pump
4 Oil filter
5 Oil pressure switch
6 Orifice
7 Camshaft
8 Main bearing
9 Crankshaft
10 Connecting rod bearing
11 Oil jet
12 Piston
13 Cylinder head
14 Cylinder block
