Form No.3351-1A-01A
F1-25
Monitor item (Display on
WDS or equivalent)
Monitoring item
Condition/
Unit
PCM terminal
TEST TEN terminal in DLC
TFT*
1
TFT °C 1M
TFTV*
1
TFT sensor signal voltage V 1M
TP TP signal voltage V 4E
TPOD TP % 4E
TRL*
1
TR switch (L range) ON/OFF 2F
TROD*
1
TR switch (D range) ON/OFF 2H
TRR*
1
TR switch (R position) ON/OFF 2E
TRD*
1
TR switch (S range) ON/OFF 2G
TSS*
1
Input/turbine speed signal rpm 2K, 2L
VPWR B+ V 1B
VSS Vehicle speed km/h 3A
*
1
: ATX only
*
2
: MTX only
SIMULATION TEST
D The simulation items of the PREMACY FP engine model are in the following table.
: Applicable
-: Not applicable
Simulation
Definition
Operation
Test condition
PCM terminal
item
Definition
Operation
IG ON IDLE
PCM terminal
ACCS A/C relay ON/OFF 1S
ALTF Generator field coil control duty value OFF ɝ 1O
CHRGLP Generator warning light ON/OFF 1Q
EVAPCP Purge solenoid valve duty value % 4L
FAN2*1 Condenser fan control ON/OFF 4J
FAN3 Cooling fan control ON/OFF 1R
FP Fuel pump relay ON/OFF 4P
FPRC Pressure regulator control ON/OFF 4T
FUELPW1 Fuel injection duration % ɝ 4W, 4X, 4Y, 4Z
IAC IAC valve % 4M, 4O
INJ_1 Fuel injector No.1 OFF ɝ 4W
INJ_2 Fuel injector No.2 OFF ɝ 4X
INJ_3 Fuel injector No.3 OFF ɝ 4Y
NJ_4 Fuel injector No.4 OFF ɝ 4Z
IVC VICS solenoid valve ON/OFF 4N
SEGRP EGR valve stepping motor position STEP 3M, 3N, 3O, 3P
*
1
: ATX only
*
2
: MTX only
