Mazda premacy - Automatic Transaxle; Outline; Cross Sectional View

Form No.3351-1A-01A
K-4
AUTOMATIC TRANSAXLE
OUTLINE
D The FN4AĆEL type automatic transaxle is used.
D The construction and operation of the automatic transaxle is the same as that of the current 323 (BJ).
CROSSĆSECTIONAL VIEW
1 Torque converter
2 Oil pump
3 Forward clutch
4 Front planetary gear
5 Rear planetary gear
6 3-4 clutch
7 Reverse clutch
8 2-4 brake band
9 Low and reverse brake
10 OneĆway clutch
11 Primary gear
12 Secondary gear
13 Output gear
14 Differential
