Form No.3351-1A-01A
F1-24
PID/DATA MONITOR AND RECORD
D The PID monitoring items of the PREMACY FP engine model for fuel and emission control systems are in the
following table.
PID/DATA Monitor Table
Monitor item (Display on
WDS or equivalent)
Monitoring item
Condition/
Unit
PCM terminal
ACCS A/C relay ON/OFF 1S
ACSW A/C switch ON/OFF 1P
ALTF Generator field coil control duty value % 1O
ALTT V Generator output voltage V 1T
ARPMDES Target engine speed rpm -
BOO Brake switch ON/OFF 1F
CHRGLP Generator warning light ON/OFF 1Q
ECT °C 3E
ECT signal voltage V 3E
EVAPCP Purge solenoid valve duty value % 4L
FAN2*
1
Condenser fan control ON/OFF 4J
FAN3 Cooling fan control ON/OFF 1R
FP Fuel pump relay ON/OFF 4P
FPRC Pressure regulator control ON/OFF 4T
FUELPW1 Fuel injection duration ms 4W, 4X, 4Y, 4Z
First gear 1/2/3/4 -
Second gear 1/2/3/4 -
Third gear 1/2/3/4 -
Fourth gear 1/2/3/4 -
IAC IAC valve ms 4M, 4O
IAT °C 3B
IAT signal voltage V 3B
IVC VICS solenoid valve ON/OFF 4N
KNOCK 1 Knocking retard degree 3G
LINEDES
Change target line pressure according to throttle opening
angle
kPa -
LPS*
1
Pressure control solenoid A 4I, 4K
MAF MAF signal voltage V 3L
O2S11 HO2S V 3C
PNP*
1
Load/no load condition signal ON/OFF 1V
PNP*
2
Load/no load condition signal ON/OFF 1V
PSP PSP switch ON/OFF 1G
RPM Engine speed rpm 3H, 3J
SEGRP EGR valve stepping motor position step 3M, 3N, 3O, 3P
SSA/SS1*
1
Shift solenoid A % 4S
SSB/SS2*
1
Shift solenoid B % 4U
SSC/SS3*
1
Shift solenoid C % 4V
SSD/SS4*
1
Shift solenoid D ON/OFF 4Q
SSE/SS5*
1
Shift solenoid E ON/OFF 4R
SPARKADV Ignition timing BTDC 3D, 3F
TCIL HOLD indicator light ON/OFF 2A
TCS HOLD switch ON/OFF 2C
*
1
: ATX only
*
2
: MTX only
