Mazda premacy - Exhaust System; Outline; Structural View

Form No.3351-1A-01A
F1-12
EXHAUST SYSTEM
OUTLINE
D The exhaust system is the same as that of the current 323 (BJ) FP engine model. (Refer to 323 Training
Manual 3327-10-98G.)
STRUCTURAL VIEW
1 Exhaust manifold
2 Front pipe
3 TWC
4 Presilencer
5 Main silencer
