CLUTCH
OUTLINE H-1..................................
OUTLINE OF CONSTRUCTION H-1............
SPECIFICATIONS H-1........................
OUTLINE
OUTLINE OF CONSTRUCTION
D The clutch mechanism is the same as that of the current 323 (BJ) models. (Refer to 323 Training Manual
3327-10-98G.)
SPECIFICATIONS
Item
Engine
Item
FP
Clutch control Hydraulic
Clutch cover
Spring type Diaphragm
Clutch cover
Set load (N {kgf, lbf}) 4,805 {490, 1,080)
Clutch disc
Outer diameter (mm {in}) 200 {7.87}
Clutch disc
Inner diameter (mm {in}) 130 {5.12}
Type Suspended
Clutch pedal Pedal ratio 6.66
Full stroke (mm {in}) 137 {5.39}
Clutch master cylinder inner diameter (mm {in}) 15.87 {0.625}
Clutch release cylinder inner diameter (mm {in}) 19.05 {0.750}
Clutch fluid type SAE J1703, FMVSS 116 DOTĆ3
