Form No.3351-1A-01A
B1-2
ENGINE MECHANISM
CYLINDER HEAD COVER
D Bosses for ignition coil installation are installed at the spark plug holes for the No.2 and No.4 cylinders on the
cylinder head cover.
1 Ignition coil installation position 2 Boss for ignition coil
