3.3.3 WIRING THE SPEAKERS
Take one of the loudspeaker cables and connect one end to the loudspeaker terminal on the


the loudspeaker. Please ensure that the red part of the cable is connected to the positive


Repeat this procedure with the second loudspeaker
cable for the other side.
C15
right speaker left speaker
Mono Power Amplier C15
left
Mono Power Amplier C15
right
