5-6-3 : Adjustment of paper ejection roller position

[1] Select the paper ejection roller position using “↑” and

“↓” keys (5 levels)

Hint !

For standard folding of standard-size paper, the paper ejection roller will be automatically set to the

optimal position for the fold position, fold type and speed.

In the case of non-standard-size paper or non-standard fold, adjust the position of the paper ejection

roller.

[ Rough indication ]

▪ For larger finished dimension ….... Paper ejection roller => To the direction to 5

▪ For smaller finished dimension ….. Paper ejection roller => To the direction to 1

▪ For higher processing speed ….….. Paper ejection roller => To the direction to 5

▪ For lower processing speed …. ….. Paper ejection roller => To the direction to 1
