6. Description of individual parts
1 Top unit with keyboard
2 Right side panel
3 Left side panel
4 Rear panel
5 Pedals
6 4 knurled screws
7 4 screws Ø 6mm x 30mm
8 5 screws Ø 4mm x 15mm
9 Cable holder with stick pad
10 Mains cable
11 2 screws Ø 6mm x 12mm
12 Pedal cable
