Rear panel LEDs
LED Status Description
Pwr A (Power A) Solid Green
Blinking Green
Solid Amber
Power Supply A is functioning.
Power Supply A is stand-by.
Power Supply A is not functioning or the unit has no power feed.
Pwr B (Power B) Solid Green
Blinking Green
Solid Amber
Power Supply B is functioning.
Power Supply B is stand-by.
Power Supply B is not functioning or the unit has no power feed.
Management Port Speed Green
Amber
O
The port speed is 10000 Mbps.
The port speed is 1000 Mbps.
Management Port Link/Act Green
Blinking Green
O
The link is up.
Data is received or transmitted.
The link is down.
Response Port Speed Green
Amber
O
The port speed is 10000 Mbps.
The port speed is 1000 Mbps.
Response Port Link/Act Green
Blinking Green
O
The link is up.
Data is received or transmitted.
The link is down.
